Infrared thermal imaging channel:
Vanadium oxide detector, 8um~14um, 17um, 384x288, <50mK@f/1.0, 30Hz
Field of view: 19°x14°
Shutter: No shutter Adaptive scene correction
Infrared resolution: 384x288
Lens: 21mm Infrared, 25mm visible light
Display modes: single infrared, single low-light, fused infrared, fused pseudo-color, fused focus (picture-in-picture)
Low-light imaging channel:
0.4um~1.2um, 2048x2048, <0.0001Lux, 30Hz
Field of view: 10 ° Manual/fully automatic
Image enhancement: Fusion of fog penetration enhancement
Image shooting: Tap to capture image/Long press to record image
Image storage: Built-in 32GSD card
Image download: USB Video display: Support PAL standard analog display
Built-in display: 720x540
LCOS Electrical interface :
Power supply, USB, analog video mechanical interface: 1/4-inch tripod Charging: USB power adapter 5VDC Battery continuous working time: ≥6h Fusion imaging range: Fusion imaging: 1.8x0.5m people; detection ≥4000m, identification ≥1500m Electronics Compass: supports three-dimensional attitude: supports fused image ranging: supports
Weight: ≤500g
Size: ≤175x88x50mm
Working temperature: -20℃~+60℃
Storage temperature: -40℃~+60℃
